Precision Investment Casting Process Water Glass Casting Parts
- Investment Casting material: carbon steel, low alloy steel, stainless steel etc.
- Casting Process: Silica Sol Investment Casting, Water Glass Investment Casting, Composite Shell Investment Casting
- Unit Component Weight: 0.05-80kgs
- Engineering Designs: OEM/ODM according to Drawings
- Standard: ASTM, AISI, JIS, EN, BS, GB etc
Features of investment casting water glass casting:
1. Simple process flow
The investment casting water glass casting process is simple and easy to use. Its simple steps and proper temperature control mean cast parts have an extremely high first-pass rate. The finished products are also more stable and reliable.
Castings made this way have relatively high surface finish and precision.
Water glass casting also called sodium silicate casting not only speeds up production, but also saves labor, materials and money effectively. From a process standpoint, it offers great benefits for workers.
2. High cost effectiveness
Water glass casting is more cost-effective than other processes like silica sol casting. Precision water glass casting processing makes high-precision, high-quality products. This means you can cut down on later processing steps.
It also controls castings’ dimensional accuracy and surface roughness well. This eliminates many manual processing steps in between, saving labor costs.So, the water glass casting process helps businesses boost production efficiency and improve economic benefits significantly.
3. High quality castings
Water glass casting ensures stable quality. By using the right raw material ratios, controlling soaking time and temperature, you can get castings with reliable forming rates, precision and surface quality. You can also test finished products in terms of size, surface quality and mechanical properties.
4. Good environmental protection
The water glass precision casting process uses renewable water glass as an additive.
Idle materials from molding production can be recycled and reused. They don’t harm the environment.
What’s more, water glass precision casting products don’t need heating or cooling during casting. There’s no obvious energy use. This makes it a low-consumption, low-pollution manufacturing process. It meets environmental protection requirements and cuts production costs too.
In short, the water glass precision casting process has several advantages. It has a simple workflow, offers good cost-effectiveness, produces high-quality castings, and is environmentally friendly.
It can meet production needs for work pieces with high demands and high quality. It also plays a positive role in boosting the demand for modern, high-end automated manufacturing.
Lantian Precision Machinery Manufacturing is a large, professional precision casting foundry in China. It has 30 years of experience. The company specializes in silica sol shell casting, water glass shell casting and composite shell processing casting.It mainly produces carbon steel investment castings, stainless steel investment castings and low alloy steel investment castings. These casting components are widely used across various industries.
Testings We Can Do:
We have complete testing equipment in our factory. In the aspects of chemical composition test: We have Italy F – 20 direct reading spectrometer, Q6 imported from Germany and domestic spectrometer analysis of the elements C, Si, Mn, P, S, Ni, Cr, Mo, V, Ti, Al, Cu, Mg, Ce, Nb, B, W;
In the aspect of physical performance testing, we can carry out tensile test, impact test, hardness detection and metallographic analysis etc.The fluorescent magnetic particle detector can also be used for magnetic particle inspection, ultrasonic inspection and colouring inspection etc as below list:
FAQ
1.Q: What material can you lost wax casting and what process?
A: Carbon steel, Low Alloy Steel and Stainless steel. We produce our oem lost wax casting parts with sodium silicate shell process, silica gel shell process and composite shell process,tooling is worked in our own workshop and also the cnc machinig work.
2. Q: What is your company’s experience and reputation in the industry?
A: Our company has been in business for almost 30 years and has a good reputation for delivering high-quality lost wax casting parts and excellent customer service. We have worked with numerous clients in various industries during the past 30 years.We have obtained China top 10 manufacture of hardware, so you can trust and rely on us.
3. Q: Are there any certifications or standards that the product meets?
A: Yes, we have ISO9001 & TS16949 Certification and follow the standards for daily production work and training in our precision foundry. And we follow the clients requirement on the casting parts, such as ASTM,AISI, JIS, GB,EF etc. If you have a different one, you can check with us freely.
4. Q: Can you provide the samples even 1 piece?
A: Yes, sample policy in our company is easy and convenient, just need you to confirm the drawing and quotation and everything, we then can work even 1 piece samples to send to you.
